Vertex Vertical TwoTier Commercial Fountain

Regular price $7,520.00
Sale price $7,520.00 Regular price
Sale Sold out
Unit price
/per
This is a pre order item. We will ship it when it comes in stock.
description


Fountain Features

  • Floating lake fountain designed for large-scale commercial application.
  • Available in 2 HP, 3 HP, and 5 HP.
  • Suggested LED Lighting Packages:
    • 2 lights for 2 HP and 3 HP
    • 3 lights for 5 HP


 Motor

HP

Center

Height

Side

Height

Spray

Diameter

2 18' 8' 20'
3 23' 10' 25'
5 26' 12' 30'


Warranty Coverage

All Vertex floating lake fountain designs go through extensive production quality control processes as well as continued testing after installation to ensure your product lasts.

  • Display heads: 4-years
  • Pumps and motors: 4-years
  • LED Lighting: 2-years
  • Control Panel: 1-year



Description

The Vertex Vertical Pond Fountain models were developed using the same strict standards as our larger models and are covered under the same warranty program with 4 year coverage for display heads, pumps and motors, 2 years on LED lighting and 1 year for the control panel.

  • Competitively priced
  • Quicker installations with a self leveling design
  • Smaller profile/lower weight makes handling easier and reduces freight costs
  • Lower maintenance costs with no oils, 0-rings or seals to change

Quality and Durability

  • Rugged, commercial grade construction stainless steel turbine pumps/motors
  • Precision machined brass/stainless steel display nozzles with defined patterns
  • Customize your displays and/or controls
  • Stainless steel LED lights


Nozzles

  • Precision stainless steel nozzles.


Pumps/Motors

  • High performance turbine pump/motor assembly
  • Stainless steel construction
  • Water cooled: no oils, seals or o-rings to replace
  • 4 year warranty


Flotation

  • Rotocast polypropylene with UV inhibitors for long life
  • Individual leveling compartments for exact adjustments
  • 4 year warranty


Control Panel

  • UL listed per National Electrical Code
  • Weatherproof steel enclosures


Submersible Light Fixtures

  • 43Watt, 120V clear, stainless steel LED light fixtures with tempered lens and neoprene gaskets, mounting brackets and fastenings of stainless steel
  • Energy efficient LED, 140 lumens
  • Stainless steel housing
  • 2 year warranty


Cables

(NOT INCLUDED IN LISTED PRICE)

- Call for price on cable

  • STW-A rated
  • 4 year warranty


Minimum Water Depth

 Motor

HP

Minimum

Depth

2 6.5'
3 6.5'
5 6.5'


Electrical Specs

 Motor

HP


Total

Wattage


Amp

Draw


Available

Phase

2 86W 0.8
1,3
3 86W 0.8
1,3
5 129W 1.1
1,3


Documentation

Vertex Vertical Pond Fountains Brochure

Vertex Vertical TwoTier System Specifications

Vertex Vertical Fountain Manual

Please see below for maximum cable lengths. All cable is sold in 25' increments.


Single Phase: 230V 60HZ

 HP 14/4 12/4 10/4 8/4 6/4 4/4 2/4
2 150' 250' 400'
3 125' 200' 300' 400'
5 175' 275' 400'
7.5 200' 300' 400'
10 150' 250' 400'
15 200' 300' 400'


3-Phase: 230V 60HZ

 HP 14/4 12/4 10/4 8/4 6/4 4/4 2/4
2 275' 400'
3 200' 400'

5 225' 325'
400'
7.5 225' 350' 400'
10 275' 400'
15 300' 400'
20 200' 350' 400'
25 275' 400'
30 300'


3-Phase: 208V 60HZ

 HP 14/4 12/4 10/4 8/4 6/4 4/4 2/4
2 225' 400'
3 175' 300' 400'
5 175' 300'
400'
7.5 200' 300' 400'
10 225' 350' 400'
15 250' 400'
20
300' 400'
25
375'
30 300'


3-Phase: 460V 60HZ

 HP 14/4 12/4 10/4 8/4
2 400'
3 400'
5 400'
7.5 400'
10 300' 400'
15 400'
20 400'
25 400'
30 400'
