Scott Aerator: Control Panel
Scott Aerator: Control Panel
Description
The Scott Control Panel is GFCI-protected and designed to operate your fountain or aerator along with a light set while only using a single power input. Your 220v or 240v power goes into the box and is split to power a 110v light set and your fountain or aerator from the same source! The Scott Control Panel also features a digital 24-hour timer, so you can optimize run times.
The Scott Control Panel is also perfect for your 230v Aquasweep or De-Icer combined with an oscillator!
- The polycarbonate enclosure is water-tight and includes mounting feet.
- Lockable, stainless steel enclosure clasps
- Digital timer has memory back-up with no battery to maintain.
- Industrial wire terminals
- Auxiliary output circuit includes a separate 15-amp breaker
- Remote start/stop circuit terminals are included
- Can be controlled by a float switch, temp switch, flow switch, or any other device with an NC control circuit.
Scott Control Panel
- ½-1½ hp, 220/240 volts
- GFCI main breaker
- 120 volt auxiliary power output
- 14" x 12" x 6" water-tight, polycarbonate enclosure
- IEC motor starter
- Adjustable overload relay
- Digital 24-hour timer controls motor starter
Be sure to disconnect power sources while swimmers are present. Test GFCI regularly to ensure proper operation.
